This subtle 22 mm diameter fixture includes a stainless steel ring.

  • Produces an eye-catching yet attractive lighting effect
  • Designed for illuminating the edges of a driveway, walkway or deck
  • Drive-over
Installation advice:

A HYVE 22 RVS every 1½ to 2 meters

In stock
Art. nr.
10104000
Specifications
General

This subtle 22 mm diameter fixture includes a stainless steel ring. In the evening, the honeycomb structure of the lens produces an attractive, warm light that is not blinding. This makes the fixture perfect in, for example, stairs and decks. The HYVE 22 stainless steel beautifully combines with the other fixtures from the HYVE range.

Product Details

Height mm
37
Height inch
1.46
Mounting depth mm
55
Mounting depth inch
2.17
Diameter Inch
1.1
Diameter mm
28
Mounting diameter mm
22
Housing
Polycarbonate
Ring/Cover plate
Stainless Steel
Voltage
12 volt
Electric potential
0.2VA
Power
0.2W
Light source
LED
Lighting direction
Upwards
Lighting reach ft
1.64
Lighting reach m
0.5
Burn time
25000
Color temperature
3000
CRI
95
Net Luminous Flux
2lm
Energy label
G
IP-class
67
Application
Deck, Driveway, Path
Processing
Concrete, Grass, Natural stone, Wood
Luminous Efficacy
10lm/W
Features
Drive-over

Installation instructions

Installation instructions
This subtle 22 mm diameter fixture includes a stainless steel ring. In the evening, the honeycomb structure of the lens produces an attractive, warm light that is not blinding. This makes the fixture perfect in, for example, stairs and decks. The HYVE 22 stainless steel beautifully combines with the other fixtures from the HYVE range.

System
Cables & transformer


Read all about the system and installation tips.
