Rosé Silver

The ACE DOWN wall fixture produces a focused beam of light and can be mounted on a wall or fence.

  • Produces a focused downward light
  • Designed for illuminating a fence or wall
  • Lighting effect can be adjusted with several accessories
Installation advice:

An ACE DOWN every 2 to 2½ meters at a height of 1.4 to 1.8 meters

Rose Silver
  • Corten
In stock
Art. nr.
10301800
Specifications
Features

The ACE DOWN wall fixture produces a focused beam of light and can be mounted on a wall or fence. The light source lies deep within the fixture to ensure the light is not blinding. The width of the light provided by the ACE DOWN can be adjusted using the separately available SHUTTER 1.


Specs

Color
Rose Silver
EAN
8717051003530
Length mm
95
Height mm
100
Width mm
64
Length inch
3.74
Height inch
3.94
Width inch
2.52
Mounting depth mm
0
Housing
Aluminium
Voltage
12 volt
Electric potential
5.3VA
Power
3W
Light source
LED
Lighting direction
Downwards
Lighting reach ft
11.48
Lighting reach m
3.5
Burning time
25000
Color temperature
3000
CRI
91
Net Luminous Flux
173lm
Energy label
G
IP-class
55
Application
Deck, Driveway, Fence, Path
Luminous Efficacy
58lm/W

Installation instructions

Installation instructions
Mount using the included screws and plugs. Watch the instructional videos on the installation tips page for information on installing the in-lite system.
