ACE HIGH CORTEN

The ACE HIGH CORTEN bollard produces a downward dispersed light on two sides, making it perfect for use between plants and ornamental grasses.

In stock
SKU
10201800
Corten
  • Corten
Go to store locator
Details

The tall bollard ACE HIGH CORTEN produces a downward dispersed light on two sides, making it perfect for use between plants and ornamental grasses. The fixture is around 50 cm high and has a light source that can be tilted 10 degrees. This lets you easily accent specific areas of the border without the light source being visible.

Unique Corten
The finish on our special Corten products is achieved through a manual process of coating, sanding, acidifying and rinsing. This makes every in-lite Corten outdoor light unique. Due to this process, the individual products may differ slightly in terms of color, texture and/or look & feel. See our blog on these products for more information.

More Information

General

General
ProductgroupSolitary
EAN8717051004261
Height mm490
Length mm86
Width mm78
Height inch19.29
Length Inch3.39
Width Inch3.07
HousingAluminium
Voltage12V
Power3W
Electric potential5.3VA
Light sourceLED
Burn time25000
Light angle360° & 90°
Lighting directionDownwards
Light distribution m3.5
Light distribution ft11.48
Color temperature3000
CRI94
Net Luminous Flux85lm
Luminous Efficacy28lm/W
IP-class55
Energy LabelA
DimmableNo
UsesBorder, Deck, Path
Installing ground lightsConcrete, Gravel, Soil
VerwerkingsadviesInstalled with screws on hard surfaces or with a peg in a soft surfaces (both included). Important: The ACE HIGH produces a downward light on two sides. The light source in the fixture is can be tilted slightly (10 degrees). For a 90-degree tiltable soft light on one side, we recommend the ACE bollard. To learn how to install the in-lite system, watch the instruction videos on the “Installation tips” page.
Installation Instructions and Downloads
Installed with screws on hard surfaces or with a peg in a soft surfaces (both included).

Important: The ACE HIGH produces a downward light on two sides. The light source in the fixture is can be tilted slightly (10 degrees). For a 90-degree tiltable soft light on one side, we recommend the ACE bollard.

To learn how to install the in-lite system, watch the instruction videos on the “Installation tips” page.

System
Cables & transformer


Read all about the system and installation tips.
