The ACE DOWN 100-230V wall light produces a targeted beam of light and can be installed on a wall or fence.

  • Produces a focused downward light
  • Designed for illuminating a fence or wall
  • Connects directly to 230 volt
Installation advice:

An ACE DOWN 100-230V every 2 to 2½ meters at a height of 1.4 to 1.8 meters

White
  • Corten
In stock
Art. nr.
10302115
Specifications
General

The ACE DOWN 100-230V wall light may only be connected to line voltage. The fixture is therefore suitable for mounting on a house, garage or shed. The fixture provides a focused beam of light downwards. The width of the light bundles provided by the ACE DOWN 100-230V can be adjusted using the separately available SHUTTER 2.

Product Details

Color
White
EAN
8717051005329
Length mm
103
Height mm
100
Width mm
100
Length inch
4.06
Height inch
3.94
Width inch
3.94
Housing
alumunium
Voltage
100-230 volt
Electric potential
11.8VA
Power
4.5W
Light source
LED
Lighting direction
Downwards
Lighting reach ft
11.48
Lighting reach m
3.5
Burn time
25000
Color temperature
3000
CRI
94
Net Luminous Flux
186lm
Energy label
G
IP-class
55
Application
Fence, House
Luminous Efficacy
41lm/W

Installation instructions

Installation instructions
The ACE DOWN 100-230V can only be connected to the regular power supply and cannot be operated using an in-lite HUB-50/HUB-100 or SMART HUB-150 12V transformer. Contact an electrician or professional for installation.
